Description

Fermator VF5+ Electronic Module Suitable For Schindler

Used For Schindler 3300/3600 elevators.

The VF may be programmed using the DIP switches on the front of the unit. If any change is made to any of the above switch selections, the main supply of Fermator VF5+ unit MUST be switched OFF and ON again to read the new programming. 1 & 2 Inputs. ON: 1 Input. The door control unit will be controlled by a single input. Any voltage between 12 V DC to 60 V DC or 100 V AC to 230 V AC applied between terminals 8 & 10 will close the doors. Without input active the door remains opened.

Open input is not used. OFF: 2 Inputs. The door control module will be controlled by two independent inputs. Any voltage between 12 V DC to 60 V DC or 100 V AC to 230 V AC applied between terminals 8 & 10 will cause the doors to close, and between terminals 10 & 12 will cause the doors to open. In the absence of a signal, the doors will remain static. If both inputs are applied then the open signal has priority.
