Description

S05VVD7-F (CE)

Multiconductor cable self-supporting for push-button panel, overhead travelling cranes, restraining fire propagation

Sheath colour BLACK

Reference rules

CEI 20-29 CEI EN 60228

IEC 228 conductor of isolated cables

CEI EN 50525 HD 21 IEC 227-1 PVC isolated cables of rated voltages up to and including 300/500 V.

CEI 20-35 CEI EN 60332-1-1 test for resistance to vertical flame propagation for a single cable

CEI EN 50363-CEI 20-11 physical characteristic CEI UNEL 00725 marking of cores electric cables

Electric characteristics

Nominal voltage Uo / U 300/500 V.

Testing voltage 2000 V.

Temperature -5° +70°

Max short circuit temperature 150°

Installation conditions

Cable for mobile specific laying

Free suspension length max 20 mt.

Bending radius minimum 10 times thickness of cable

Tensile stress 15N for mm2 of copper cross section

Operating temperature 0°
