Size (WxDxH): 10x28x2000mm.
• Detecting Height: 20mm to 1849mm.
• Number of IR diodes: 17.
• Scan beams (distance > 400mm): 94 beams.
• Scan beams (distance < 400mm): 33 beams.
• Opening: 0mm – 4000mm.
• Ideal for both static and dynamic mounting.
• Light Immunity: 100,000 LUX.
• Operating Temperature: -20°C ~ +65°C.
• Buzzer: after continuous detection for 15s buzzer on (when BUZZER
SWITCH=ON).
• Cable length: 4 mt.
• Vandalism detection: 60 sec., 3 non-adjacent diodes.
• IP:54.
