VEGA Push Buttons Venus XL
Description
VEGA Push Buttons Venus XL
Vandal resistant push button with braille.
- Body: nylon push button.
- Bezels: stainless steel (Ø 38,2mm).
- Pressel: polycarbonate with stainless steel AISI 304 or gold/black pvd coated finishes; illuminable raised legend(s) and Braille.
- Mounting: the button is put into the cutout (Ø 32,2) from the front and fixed by threaded ring.
- Faceplate Thickness: 0,7 mm to 5 mm.
- Contacts: 1 micro switch or 2 micro switches.
- Wiring: PIN or pre-wired connectors (AMP, JST or minispox).
- Illumination: Led 12V o 24V DC 30mA.
- Stroke: 1,2 mm.
- life: 2.000.000 activations.
- Degree of protection: IP51 with metal spring/IP54 with silicone spring and o-ring.
